Key Product Highlights
- Gate-Friendly Maneuverability: Designed with an ultra-narrow chassis, letting you bypass standard property gates and work in tight zero-lot-line residential zones seamlessly.
- High-Torque 23HP Gas Power: Outfitted with a reliable, electric-start V-twin engine that eliminates the cold-starting hassle and noise of traditional diesel engine
- Low-Ground-Impact Rubber Tracks: Sturdy 7-inch wide tracks distribute the machine’s weight evenly, maximizing traction across mud and steep 30° slopes while safeguarding delicate lawns.
- Auxiliary Hydraulic Control with Detent: Features continuous-flow front auxiliary ports equipped with a locking detent lever—perfect for running high-demand attachments like trenchers, log splitters, or augers continuously without hand fatigue.
- Ergonomic Stand-On Platform: The cushioned rear operator platform features integrated hydraulic dampening to reduce lower back fatigue on rough turf and flips up completely to shorten the machine’s length for tight trailering.
Technical Specifications
| Feature | Specification |
| Engine Plant | 23 HP V-Twin Gasoline Engine (Electric Start) |
| Machine Weight | Approx. 2,000 lbs (Empty / Operating) |
| Rated Operating Capacity | 440 to 485 lbs (Up to 800+ lbs safe lift with counterweights) |
| Hydraulic System Output | 11.4 GPM @ 2,320 to 2,466 PSI |
| Maximum Pin/Lift Height | Approx. 71 to 72 Inches (5’11” max pin clearance) |
| Machine Width | 38″ to 43″ wide depending on bucket track profile |
| Total Length | 7’4″ (Platform Down) / 6’8″ (Platform Flipped Up) |
| Fuel Capacity | 1.7 to 6.6 Gallon capacity (Runs regular unleaded 92# gas) |
Common Residential & Commercial Applications
- Backyard Hardscaping: Moving heavy pavers, retaining wall blocks, crushed limestone, and bedding sand into enclosed yards.
- Trenching & Drainage: Operating attachment augers and trenchers right up against structural foundations or fences.
- Tree & Land Clearing: Hauling logs, clearing stubborn brush piles, and carrying heavy nursery root balls.
- Site Preparation: Grading dirt, fixing driveway washouts, leveling topsoil blocks, and spreading heavy playground mulch.
